AYA 3 Watt Isolated DC-DC Converter

Active

Industrial DC-DC

The AYA series isolated industrial DC-DC converters are suitable for a diverse range of low-power applications, including data communication, telecommunication and computer peripheral equipment, industrial automation, and mobile battery-powered systems.

Fully encapsulated in an ultra-compact plastic case just 0.32 inch high, these 3 W converters operate at a temperature range of -40 to 85˚C (with derating) and provide efficiency of up to 80%. The converters switch at a fixed frequency, minimizing the need for external EMI filtering and complying with the EN 55022 class A and FCC level A standards for conducted noise.

Choose from 28 variants, all featuring wide input voltage (4.5 to 10 V, 9 to 18 V, 18 to 36 V, or 36 to 75 V) in single- or dual-output models offering voltages of 3.3 V, 5 V, 12 V, 15 V, or +5/-5 V, +12/-12 V, or +15/-15 V, respectively. The parts are available in a mini dual-in-line (for through-hole) or surface-mount package.


Features

  • Input voltage range 4.5V to 10V
  • Input voltage range 9V to 18V
  • Input voltage range 18V to 36V
  • Input voltage range 36V to 75V
  • Output voltage (Single) 3v3, 5v, 12v, 15v
  • Output voltage (Dual) +/-5V, +/-12V, +/-15V
  • Isolation voltage 1500Vdc

Benefits

  • Output voltage Single and Dual O/P versions
  • Mechanical Fully potted
  • Terminal Through Hole

Specifications

Output Power (W): 3
Length (Inches): 0.55
Width (Inches): 0.55
Height (Inches): 0.31
Mounting Type: BMP; Through Hole
Minimum Output Current (A): 0.1
Maximum Output Current (A): 0.6
Output Voltage Range (V): -15V to 15V
All Specifications

Stock Check

Model Number Min. Voltage (V) Max. Voltage (V) Current (A) Nominal Voltage (V) Number of Outputs Samples Buy
AYA01A05-L
4.5-10Vin, 5V at 600mA
5 5 0.6 5 1 Contact Us Contact Us
AYA01A12-L Active, In Stock
9-18Vin, 5V at 600mA
5 5 0.6 5 1 Request Buy
AYA01A24-L Active, In Stock
18-36Vin, 5Vat 600mA
5 5 0.6 5 1 Request Buy
AYA01A48-L Active, In Stock
36-75Vin, 5V at 600mA
5 5 0.6 5 1 Request Buy
AYA01AA05-L Active, In Stock
4.5-10Vin, +/-5V at 300mA
0 0 0 0 2 Request Buy
AYA01AA12-L Active, In Stock
9-18Vin, +/-5V at 300mA
5 5 0.3 5 2 Request Buy
AYA01AA24-L Active, In Stock
18-36Vin, +/-5V at 300mA
5 5 0.3 5 2 Request Buy
AYA01AA48-L
36-75Vin, +/-5V at 300mA
5 5 0.3 5 2 Contact Us Contact Us
AYA01B05-L Active, In Stock
4.5-10Vin, 12V at 250mA
12 12 0.25 12 1 Request Buy
AYA01B12-L Active, In Stock
9 -18Vin, 12V at 250mA
12 12 0.25 12 1 Request Buy
AYA01B24-L Active, In Stock
18-36Vin, 12V at 250mA
12 12 0.25 12 1 Request Buy
AYA01B48-L Active, In Stock
36-75Vin, 12V at 250mA
12 12 0.25 12 1 Request Buy
AYA01BB05-L Active, In Stock
4.5-10Vin,+/-12V at 125mA
12 12 0.125 12 2 Request Buy
AYA01BB12-L Active, In Stock
9-18Vin,+/-12V at 125mA
12 12 0.125 12 2 Request Buy
AYA01BB24-L
18-36Vin,+/-12V at 125mA
12 12 0.125 12 2 Contact Us Contact Us
AYA01BB48-L Active, In Stock
36-75Vin,+/-12V at 125mA
12 12 0.125 12 2 Request Buy
AYA01C05-L Active, In Stock
4.5-10Vin, 15V at 200mA
15 15 0.2 15 1 Request Buy
AYA01C12-L Active, In Stock
9-18Vin, 15V at 200mA
15 15 0.2 15 1 Request Buy
AYA01C24-L Active, In Stock
18-36Vin, 15V at 200mA
15 15 0.2 15 1 Request Buy
AYA01C48-L Active, In Stock
36-75Vin, 15V at 200mA
15 15 0.2 15 1 Request Buy
AYA01CC05-L Active, In Stock
4.5-10Vin,+/-15V at 100mA
15 15 0.1 15 2 Request Buy
AYA01CC12-L Active, In Stock
9-18Vin,+/-15V at 100mA
15 15 0.1 15 2 Request Buy
AYA01CC24-L
18-36Vin,+/-15V at 100mA
15 15 0.1 15 2 Contact Us Contact Us
AYA01CC48-L
36-75Vin,+/-15V at 100mA
15 15 0.1 15 2 Contact Us Contact Us
AYA01F05-L Active, In Stock
4.5-10Vin, 3.3V at 600mA
3.3 3.3 0.6 3.3 1 Request Buy
AYA01F12-L Active, In Stock
9-18Vin, 3.3V at 600mA
3.3 3.3 0.6 3.3 1 Request Buy
AYA01F24-L Active, In Stock
18-36Vin, 3.3V at 600mA
3.3 3.3 0.6 3.3 1 Request Buy
AYA01F48-L Active, In Stock
36-75Vin, 3.3V at 600mA
3.3 3.3 0.6 3.3 1 Request Buy
