AVO50 Series

Active

24 to 50 W Eighth-Brick Isolated DC-DC Converters

The AVO50 series of eighth-brick isolated DC-DC converters comprises seven single output models offering fully regulated voltages of 1.2 V, 1.5 V, 1.8 V, 2.5 V, 3.3 V, 5.0 V or 12.0 V. These converters can deliver up to 20 A and up to 50 W, depending on the particular model. They have a wide 2:1 input range of 36 to 75 VDC and are designed primarily for use with standard 48 V telecommunications equipment supplies, forced air, and conduction cooling. AVO50 series converters have an installed height of just 0.36 inch (9 mm), making them ideal for systems with demanding inter-board spacing requirements.


Features

  • Delivers up to 25A output current
  • Trim function: +10%/20%
  • Ultra high efficiency: 91% at 5V full load
  • Input voltage 36VDC to 75VDC
  • output voltage 1.2VDC to 12VDC

Benefits

  • Basic isolation
  • CNT function
  • High power density
  • Improved thermal performance
  • Industry standard eighth brick foot print
  • Low output noise
  • Remote sense
  • RoHS compliant
  • isolation basic insulation

Specifications

Output Power (W): 50
Length (Inches): 2.28
Width (Inches): 0.9
Height (Inches): 0.35
Mounting Type: BMP; Through Hole
Minimum Output Current (A): 4.2
Maximum Output Current (A): 20
Output Voltage Range (V): 1.2V to 12V
All Specifications Collapse Specifications

Stock Check

Model Number
Min. Voltage (V) Max. Voltage (V) Current (A) Nominal Voltage (V) Number of Outputs Samples Buy
AVO50-48S05-4 Active, Contact Us
5V 10A Eighth brick
5 5 10 5 1 Contact Us Buy
AVO50-48S12-6L Active, Contact Us
12V 4.2A Eighth brick
12 12 4.2 12 1 Contact Us Buy
AVO50-48S12P-4 Active, Contact Us
12V 4.2A Eighth brick
0 Contact Us Buy
AVO50-48S1V2-4 Active, Contact Us
1.2V 20A Eighth brick
1.2 1.2 20 1.2 1 Contact Us Buy
AVO50-48S1V2P-4 Active, Contact Us
1.2V 20A Eighth brick
0 Contact Us Buy
AVO50-48S1V5-4 Active, Contact Us
1.5V 20A Eighth brick
1.5 1.5 20 1.5 1 Contact Us Buy
AVO50-48S1V5P-4 Active, Contact Us
1.5V 20A Eighth brick
1.5 1.5 20 1.5 1 Contact Us Buy
AVO50-48S1V8-4 Active, Contact Us
1.8V 20A Eighth brick
1.8 1.8 20 1.8 1 Contact Us Buy
AVO50-48S1V8P-4 Active, Contact Us
1.8V 20A Eighth brick
0 Contact Us Buy
AVO50-48S2V5-4 Active, Contact Us
2.5V 20A Eighth brick
2.5 2.5 20 2.5 1 Contact Us Buy
AVO50-48S2V5P-4 Active, Contact Us
2.5V 20A Eighth brick
0 Contact Us Buy
