High Power 40C to 60C Series
Active
Capacitor-Charging Supply with Regulatd High Voltage Outputs 40,000 to 60,000 VDC Maximum
The High Power C series of regulated DC-to-DC supplies is optimal for your laser, capacitor charging, pulsed power, pulse generator, and test equipment applications. A wide range of high-power-density models allows you to cover an output range of 40,000 VDC to 60,000 VDC. Available in single-output positive or negative polarities, the supplies offer from 60 W to 250 W of fast-rise charging power with less than 1% overshoot and ＜10,000 ppm ripple from a 24 VDC input. The series offers voltage/current control and monitoring from one of the several available analog interfaces and features a temperature coefficient of 50 and 25 ppm/℃. Various electrical and mechanical integration options are available.
Features
- Fast-rise charging power delivered from an optimized design
- Limited overshoot, typically less than 1% of high voltage setpoint, depending on the application
- High power-to-package size ratio
- Full-featured analog interface includes voltage/current controls and monitors
- Selection of electrical and mechanical integration options
Benefits
- Reduce system footprint and simplify packaging requirements
- Achieve higher system throughput with quick capacitor charging
- Minimize stress on storage capacitors, enhance system reliability, simplify product design
- Provide more responsive and adaptable control of high voltage capacitor charging
- Expand mechanical integration and interconnection possibilities
Technical Documentation
Product Information Documents
Engineering Resources
Compare
| Model | High Power 40C to 60C Series | A Series | C Series | LE Series |
|---|---|---|---|---|
| Length (Inches) | 3.7 | |||
| Width (Inches) | 1.5 | |||
| Height (Inches) | 0.8 | |||
| Output Voltage Range (V) | 0 to 40,000 | 0 to 6000 | 0 to 30000 | |
| Maximum Output Power (W) | 30 | 30 | 30 |
