Trek 646 Series

Active

Software-Driven Electrostatic Chuck Supply, Output Voltage Range 0 to ±3 kV

The Trek® 646 software-driven electrostatic chuck supply offers an array of features that accommodate a variety of demanding applications. The instrument incorporates Advanced Energy technology which has demonstrated increased efficiency and throughput equal to three times that of other supplies. The versatile trusted performance of the Trek 646 allows for use in multiple unique tools and processes that eliminates the need to specify a new supply for each unique tool or process in a facility.

Features

  • Lockable front panel control interface
  • NIST-traceable calibration certificate provided with each unit
  • Supports both Coulombic and Johnsen-Rahbek ESC technologies
  • Upload and store electrostatic chuck profiles to the unit and stored internally via a user-friendly software interface
  • Wafer detection includes no-wafer, wafer-present or wafer-clamped status

Benefits

  • Reduce backside gas errors, increases throughput, and eliminate sticky/popping wafer issues
  • Control parameters such as over-current, wafer-present, and wafer-clamped thresholds, clamp voltage, offset voltage and internal or external amplitude/offset control
  • Adjust in-process amplitude/offset and output-control versatility
  • Control output using the back panel I/O, serial computer command, or front panel controls
  • Configure for custom clamp and declamp sequences and wave shapes

Specifications

Output Power (W): 19.5
Maximum Output Current (A): ±0.0065
Slew Rate (V/ms): -
Output Voltage Range (V): 0 to ±3000

Accessories

Trek 645/646 Application Software

Trek 645 and Trek 646 Application Software
