HV Rack Series


Rack-Mount, High Voltage Power Systems

Accurately control and measure your high voltage power supplies and HV system performance. HV Rack® configurable power systems enable you to select, control, and monitor your high voltage power supplies within each output channel.  You can select power supplies from Advanced Energy's UltraVolt’ s A, C, E, High Power C, and FIL series.


  • Up to four configurable high-voltage outputs
  • Ideal for various beam applications
  • Can provide floating filament 0 to 5 VDC/0 to 3 A when used with the FIL5V-3A
  • Current mode and voltage mode indicator
  • Several options and unites


  • Power up to four power supplies
  • Adjust voltage and current on each channel
  • Ensure proper filament operation for maximum performance and precision
  • Reduce voltage to 0 VDC
  • Increase channel power (up to 1000 W) via parallel units


Output Power (W): 250 to 1000
Minimum Output Power (W): 250
Maximum Output Power (W): 1000
Maximum Input Voltage (V): 230
