artesyn™

NP08

Active

Up to 4000 W Configurable AC-DC Power Supplies

The NeoPower NP08 AC-DC configurable power supply introduces best-in-class power density of 18 W/in3. For up to 4000 W output power in a 283.4 x 203.2 x 63.5 mm package, NP08 is easy to configure (series or parallel) and has eight output power slots. The NP08  case can be populated with up to 8 output modules, providing up to 8 isolated DC outputs that range from 1.0 to 57.6 V. The NP05 can drop into an OEM’s enclosure to make a custom power supply or simply be used for its high flexibility for any embedded or power conversion challenge requiring multiple outputs.​

The NeoPower is certified for both industrial IEC/EN/UL 62368-1  and medical IEC/EN 60601-1 safety approvals, including compliance to the SEMI F47 standard.

Features

  • Market-leading low ripple noise​
  • Programmable in constant voltage or constant current mode​
  • MTBF > 500,000 hours​
  • Five-year warranty

Benefits

  • More power in 2.5" configurable compared to the competition​
  • Flexible communications​
  • Fast deployment​
  • Higher power signal and accuracy​
  • Simplified busbars for any series/parallel combination​
  • Confidence in reliability from the #1 configurable power supply manufacturer

Specifications

Length (Inches): 11.2
Width (Inches): 8
Height (Inches): 2.5
Output Voltage Range (V): 1 to 300
Maximum Output Power (W): 4000
Minimum Input Voltage (V): 90
Maximum Input Voltage (V): 264

Accessories Stock Check

J1 SIGNAL ASSY,HARN,14,14 WAY COMMS CONNECTOR
83-200-001
Active, In Stock
PowerPro MODBUS RTU to CANBUS/PMBUS Dongle
PowerPro MODBUS RTU to MODBUS TCP Ethernet Dongle
83-778-002
Active, In Stock
NeoPower(NP) 2x 1-slot module, single output parallel kit
83-778-003
Active, In Stock
NeoPower(NP) 3x 1-slot module, single output parallel kit
83-778-004
Active, In Stock
NeoPower(NP) 4x 1-slot module, single output parallel kit
83-778-005
Active, In Stock
NeoPower(NP) 5x 1-slot module, single output parallel kit
83-778-006
Active, In Stock
NeoPower(NP) 6x 1-slot module, single output parallel kit
83-778-007
Active, In Stock
NeoPower(NP) 7x 1-slot module, single output parallel kit
83-778-008
Active, In Stock
NeoPower(NP) 8x 1-slot module, single output parallel kit
83-778-009
Active, In Stock
NeoPower(NP) 2x 1-slot module, single output series kit
83-778-010
Active, In Stock
NeoPower(NP) 3x 1-slot module, single output series kit
83-778-011
Active, In Stock
NeoPower(NP) 4x 1-slot module, single output series kit
83-778-012
Active, In Stock
NeoPower(NP) 5x 1-slot module, single output series kit
83-778-013
Active, In Stock
NeoPower(NP) 6x 1-slot module, single output series kit
83-778-014
Active, In Stock
NeoPower(NP) 7x 1-slot module, single output series kit
83-778-015
Active, In Stock
NeoPower(NP) 8x 1-slot module, single output series kit
RJ45 MODBUS programming cable
