tegam ®

Datalogging Calibrators

Active

Handheld Digital Temperature Calibrator with Bluetooth®

Our datalogging calibrator provides highly portable laboratory-grade calibrations with leading accuracy and battery life. With all of the features available on the thermocouple calibrators (940A & 945A), the 948A also offers wireless connectivity and wireless ISO 17025 Calibration Reports through Bluetooth® technology. These calibrators can be used on-site to perform calibrations and verifications of thermocouples, temperature transmitters, indicators, process controllers and displays with lab-grade accuracy in the varied conditions found on the plant floor.




Features

  • Source Accuracy: ±0.005% +5 µV
  • Resolution: 0.01 ⁰
  • Thermocouple calibrator features 10X Battery Life
  • This Temperature Calibrator Features Simultaneous Source/Measure
  • MIL-STD Durability
  • SSO 17025 Cal standard; AMS 2750 calibration optional
  • Easy One-Hand Operation
  • Assembled in the USA

Benefits

  • Source and measure using one instrument
  • Superior accuracy assures your thermal equipment is working properly
  • Automatic ambient temperature compensation maintains accuracy in diverse conditions
  • One-key operation for common industry calibrations
  • Sealed keypad and contoured surfaces for easy cleaning
  • Preset options foster quick calibration for different equipment
  • Long battery life and easily replaceable batteries keep your calibrator in continuous operation

Specifications

Basic Accuracy: 0.005%
Range: 15 to 85 mV
Resolution (°C): 1 µV, 0.1⁰
Temp. Scale: C, F, K, mV

Stock Check

Model Number
Accuracy No. of TCs Supported Range Resolution Temp. Scale Buy
945-2750 Active
AMS2750E Cal Option
Buy
948A Active
Wireless Datalogging Thermocouple Calibrator; 14 TCs
±(0.005% rdg + 5µV) 14 15 to 85 mV 1 µV, 0.1⁰ C, F, K, mV Buy

Recommended Probes (Note, calibrators do not include temperature probes.)

Accessories Stock Check

940-912E
Active
Calibration Adapter Cable, Type E, Mini T/C Connector

For use with TEGAM Thermocouple Calibrators. Includes a 3’ calibration cable terminated with a male MTC and ¼” spade lug; a standard thermocouple connector; and a standard to male mini adapter. Also Available in Types: J, K, T, U, R/S or N. Sensor Type E.


940-912K
Active
Calibration Adapter Cable, Type K, Mini T/C Connector

For use with TEGAM Thermocouple Calibrators. Includes a 3’ calibration cable terminated with a male MTC and ¼” spade lug; a standard thermocouple connector; and a standard to male mini adapter. Also Available in Types: J, T, E, U, R/S or N. Sensor Type K.

940-912U
Active
Calibration Adapter Cable, Type U. Mini T/C Connector

For use with TEGAM Thermocouple Calibrators. Includes a 3’ calibration cable terminated with a male MTC and ¼” spade lug; a standard thermocouple connector; and a standard to male mini adapter. Also Available in Types:  K, T, E, J, R/S or N. Sensor Type U.

940-912T
Active
Calibration Adapter Cable, Type T. Mini T/C Connector

For use with TEGAM temperature calibrators. The Calibration Kit includes four 3’ cal cables of each Type K, J, T & E terminated with a male MTC connector and copper alligator clips; a 9K002MTC36 3’ Type K wire thermocouple sensor; all packaged in a 911-911 foam-filled hard carry case with room for your temperature calibrator, calibration cables, temperature probes and other small tools and accessories.

Calibration Adapter Cable, Type R/S. Mini T/C Connector

For use with TEGAM Thermocouple Calibrators. Includes a 3’ calibration cable terminated with a male MTC and ¼” spade lug; a standard thermocouple connector; and a standard to male mini adapter. Also Available in Types:  K, T, E, J, U or N. Sensor Type R/S

940-912N
Active
Calibration Adapter Cable, Type N, Mini T/C Connector

For use with TEGAM Thermocouple Calibrators. Includes a 3’ calibration cable terminated with a male MTC and ¼” spade lug; a standard thermocouple connector; and a standard to male mini adapter. Also Available in Types:  K, T, E, J, U, or R/S . Sensor Type N.


940-912J
Active
Calibration Adapter Cable, Type J, Mini T/C Connector

For use with TEGAM Thermocouple Calibrators. Includes a 3’ calibration cable terminated with a male MTC and ¼” spade lug; a standard thermocouple connector; and a standard to male mini adapter. Also Available in Types:  K, T, E, U, R/S or N. Sensor Type J.

940-913
Active
Alligator Calibration Cable Kit, T/C Types J/K/T/E

For use with TEGAM temperature calibrators. The Calibration Kit includes four 3’ cal cables of each Type K, J, T & E terminated with a male MTC connector and copper alligator clips; a 9K002MTC36 3’ Type K wire thermocouple sensor; all packaged in a 911-911 foam-filled hard carry case with room for your temperature calibrator, calibration cables, temperature probes and other small tools and accessories.

945-2750
Active
SAE AMS 2750 Calibration Option (4 Thermocouples); 94x Series Calibrators
900-913
Active
Belt Clip for 700 and 900 Series Meters

Factory or User Installed Belt Clip
This clip allows the user to attach a 700 or 900 series meter quickly and easily to a belt. Frees hands for other tasks. Can be installed at purchase of handheld meter or purchased and installed separately at a later date.
NOTE: This product is not compatible with the tilt stand or magnet holders.

Technical Specifications
Attaches easily to TEGAM’s 900 and 700 Series handheld meters
Frees operators’ hands for other tasks.

900-914
Active
Belt Clip for 700 & 900 Series (User Installed)
911-910
Active
Tilt Stand / Magnetic Hanger for 900 Series (Factory Installed)

Tilt Stand, Magnet, Hanger is an optional accessory for the TEGAM 911A, 912A, 931A or 932A handheld thermometers. It is Factory Installed with purchase of 900 series thermometer. The hanger attaches to the back of the handheld thermometer so that professionals may free their hands while taking temperature measurements.

Technical Specifications
Purchased with a thermocouple thermometer and IS installed prior to shipping
Attaches easily to the back of TEGAM’s 911A, 912A, 931A or 932A
Allows professionals to free their hands while taking temperature measurements
Versatile

911-911
Active
Foam-filled Hard Carry Case for 900 Series

Foam-filled hard carry case is an optional accessory for the TEGAM 911B, 912B, 931B or 932B handheld digital thermometers and the TEGAM 940A or 945A handheld temperature calibrators.

The case has a place for your handheld instrument, probes, and additional batteries.

Technical Specifications
Durable
Custom fit
Protects Equipment

911-912
Active
Tilt Stand / Magnetic Hanger for 900 Series (User Installed)

Tilt Stand, Magnet, Hanger is an optional accessory for the TEGAM 911B, 912B, 931B or 932B handheld thermometers.  The hanger attaches to the back of the handheld thermometer so that professionals may free free their hands while taking temperature measurements.

Technical Specifications
Product is individually packed and is NOT installed on a thermocouple thermometer
Attaches easily to the back of TEGAM’s 911B, 912B, 931B or 932B
Allows professionals to free their hands while taking temperature measurements
Versatile
