artesyn™
iHP12/15 Air Cooled
Active
12k to 15k W Configurable AC-DC Power Supplies
The iHP12/15 Air Cooled precision AC-DC configurable power supply is 100% digitally controlled in a 456.2 mm x 447.0 mm x 132.5 mm package and provides eight individual slots that accept intelligent DC-DC converter modules. Each slot may be populated with a separate 3000 W plug-in module with an output voltage range from 0.6 VDC to 300.0 VDC (with eight nominal voltages) for a total output power of 12 kW. For more power with fewer outputs (up to two), the 12 kW modules from 2.5 to 360.0 VDC (with 50 or 300V nominal), which occupy three slots, provides 12kW, leaving one slot available for 3000 W modules to provide up to 15 kW in the standard iHP12 case at 480 VAC 3-phase, nominal input.
The iHP12/15 offers developers either an analog (0-5/10V) or digital interface supporting standard communications protocols, while a downloadable software GUI allows for easy configuration and user dashboard creation. The series EN/UL 62368 industrial and IEC/EN/UL 60601-1 medical safety approvals and is SEMI F47 compliant. For horticulture, GROWINSIGHT™ detailed scheduling and control software is available.
The iHP12/15 offers developers either an analog (0-5/10V) or digital interface supporting standard communications protocols, while a downloadable software GUI allows for easy configuration and user dashboard creation. The series EN/UL 62368 industrial and IEC/EN/UL 60601-1 medical safety approvals and is SEMI F47 compliant. For horticulture, GROWINSIGHT™ detailed scheduling and control software is available.
Features
- Market-leading low ripple noise
- Fast current slew rate up to 200 Hz
- Single-phase and 3-phase (208/240, 380/480 VAC nominal) input options
- MTBF > 500,000 hours
- Five-year warranty
Benefits
- Higher power density consumes less physical space
- Flexible communications
- Fast deployment with user- and field-configurability.
- Simplified busbars for any series/parallel combinations
- Confidence in reliability from the #1 configurable power supply manufacturer
Specifications
| Length (Inches): | 27.8 |
|---|---|
| Width (Inches): | 17.6 |
| Height (Inches): | 5.22 |
| Output Voltage Range (V): | 0.6 to 1000 |
| Maximum Output Power (W): | 15000 |
| Minimum Input Voltage (V): | 180 |
| Maximum Input Voltage (V): | 660 |
Introducing ConfigPro
Advanced Energy’s Revolutionary Online Power Configurator
With over 3 million configurable power supply combinations, this power solution algorithm optimizes cost and guides you to the ideal solution for MP, IMP, IVS, and MICROMP (UMP) configurable power supply families.
Get Started
Technical Documentation
Product Information Documents
Safety & Compliance Certificates
Guides & Manuals
Engineering Resources
Insights & Studies
Miscellaneous
New
Technical Videos
iHP Group digital voltage source setup
Aug 1, 2017
Designed for a wide range of medical and industrial applications, Artesyn’s iHP configurable intelligent power system provides accuracy, resolution and stability as either a programmable voltage or current source. It provides up to 24 kW in 3 kW increments and can be configured for up to 8 outputs using a wide variety of plug-in modules that address a large range of voltages and currents. The modules can be connected in series or parallel, and Group is defined accordingly via GUI. User can just send commands to Group replacing individual module control.
