MPM Series
Active
Compact, Proportional, DC-DC Power Supplies
Advanced Energy's UltraVolt MPM series of reliable, general-purpose high voltage modules features eight compact, PCB-mountable form factors that range from 100 to 3000 VDC. All modules deliver up to 1.5 W of power from a 12 or 24 VDC input. Single-output positive or negative polarities are available. Reversed input polarity, intermittent-output, and open-/short-circuit protection is standard. Choose from non-isolated and isolated output options and select shielded or unshielded configurations to guard output from external radiated emissions.
Eigenschaften
- Single pin provides both module power and control of high voltage output
- Compact, low-profile, PCB-mountable package
- Selection of high voltage outputs: 100 to 3000 VDC, positive or negative polarity
- Input polarity protection; output protection from intermittent open- or short-circuits
- Available input/output isolation to 100 VDC, metal shielding options
Vorteile
- Simplify high voltage subsystem design
- PCB size and enclosure packaging requirements
- Upgrade module and system performance without changing PCB layout
- Increase power subsystem robustness
- Add protection from line noise and external RF emissions
Spezifikationen
| Ausgangsleistung (W): | 1.5 |
|---|---|
| Länge (Zoll): | 1.5 |
| Breite (Zoll): | 1.5 |
| Höhe (Zoll): | 0.79 |
| Montage Typ: | Through Hole, Surface Mount |
| Maximaler Ausgangsstrom (A): | 0.015 |
| Ausgangsspannungsbereich (V): | 500 to 3000 |
| Maximale Ausgangsleistung (W): | 1.5 |
| Minimum Input Voltage (V): | 0 |
| Maximale Eingangsspannung (V): | 45284 |
Lagerbestand prüfen
|
Modellnummer
Proben
Kaufen
|
Kontrolle Typ | Maximale Ausgangsleistung (W) | Maximale Ausgangsspannung (V) | Anzahl der Ausgänge | Restwelligkeit (ppm) | Temperatur-Koeffizient | Ausgangstyp | Proben | Kaufen |
|---|---|---|---|---|---|---|---|---|---|
| MPM12-100N Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-100NS Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 2500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-100P Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-100PS Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 2500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-1K5N Active, Kontakt | Proportional | 1.5 | 1.5 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-1K5NS Active, Kontakt | Proportional | 1.5 | 1.5 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-1K5P Aktiv, Vorrätig | Proportional | 1.5 | 1.5 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-1K5PS Aktiv, Vorrätig | Proportional | 1.5 | 1.5 | 1 | 500 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-1KN Aktiv, Vorrätig | Proportional | 1.5 | 1 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-1KNS Aktiv, Vorrätig | Proportional | 1.5 | 1 | 1 | 500 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-1KP Active, Kontakt | Proportional | 1.5 | 1 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-1KPS Active, Kontakt | Proportional | 1.5 | 1 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-200N Active, Kontakt | Proportional | 1.5 | 0.2 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-200NS Active, Kontakt | Proportional | 1.5 | 0.2 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-200P Aktiv, Vorrätig | Proportional | 1.5 | 0.2 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-200PS Active, Kontakt | Proportional | 1.5 | 0.2 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-2KN Aktiv, Vorrätig | Proportional | 1.5 | 2 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-2KNS Active, Kontakt | Proportional | 1.5 | 2 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-2KP Aktiv, Vorrätig | Proportional | 1.5 | 2 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-2KPS Aktiv, Vorrätig | Proportional | 1.5 | 2 | 1 | 500 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-300N Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-300NS Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-300P Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-300PS Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-3KN Active, Kontakt | Proportional | 1.5 | 3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-3KNS Aktiv, Vorrätig | Proportional | 1.5 | 3 | 1 | 500 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-3KP Active, Kontakt | Proportional | 1.5 | 3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-3KPS Active, Kontakt | Proportional | 1.5 | 3 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-500N Aktiv, Vorrätig | Proportional | 1.5 | 0.5 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-500NS Active, Kontakt | Proportional | 1.5 | 0.5 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM12-500P Aktiv, Vorrätig | Proportional | 1.5 | 0.5 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM12-500PS Aktiv, Vorrätig | Proportional | 1.5 | 0.5 | 1 | 500 | 300 | Unipolar | Anfrage | Kaufen |
| MPM24-100N Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-100NS Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 2500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-100P Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-100PS Active, Kontakt | Proportional | 1.5 | 0.1 | 1 | 2500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-1K5N Active, Kontakt | Proportional | 1.5 | 1.5 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-1K5NS Active, Kontakt | Proportional | 1.5 | 1.5 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-1K5P Active, Kontakt | Proportional | 1.5 | 1.5 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-1K5PS Active, Kontakt | Proportional | 1.5 | 1.5 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-1KN Aktiv, Vorrätig | Proportional | 1.5 | 1 | 1 | 5000 | 300 | Unipolar | Anfrage | Kaufen |
| MPM24-1KNS Active, Kontakt | Proportional | 1.5 | 1 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-1KP Active, Kontakt | Proportional | 1.5 | 1 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-1KPS Active, Kontakt | Proportional | 1.5 | 1 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-200N Active, Kontakt | Proportional | 1.5 | 0.2 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-200NS Aktiv, Vorrätig | Proportional | 1.5 | 0.2 | 1 | 500 | 300 | Unipolar | Anfrage | Kaufen |
| MPM24-200P Active, Kontakt | Proportional | 1.5 | 0.2 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-200PS Active, Kontakt | Proportional | 1.5 | 0.2 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-2KN Active, Kontakt | Proportional | 1.5 | 2 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-2KNS Active, Kontakt | Proportional | 1.5 | 2 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-2KP Active, Kontakt | Proportional | 1.5 | 2 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-2KPS Active, Kontakt | Proportional | 1.5 | 2 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-300N Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-300NS Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-300P Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-300PS Active, Kontakt | Proportional | 1.5 | 0.3 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-3KN Active, Kontakt | Proportional | 1.5 | 3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-3KNS Active, Kontakt | Proportional | 1.5 | 3 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-3KP Active, Kontakt | Proportional | 1.5 | 3 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-3KPS Active, Kontakt | Proportional | 1.5 | 3 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-500N Active, Kontakt | Proportional | 1.5 | 0.5 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-500NS Active, Kontakt | Proportional | 1.5 | 0.5 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-500P Active, Kontakt | Proportional | 1.5 | 0.5 | 1 | 5000 | 300 | Unipolar | Kontakt | Kaufen |
| MPM24-500PS Active, Kontakt | Proportional | 1.5 | 0.5 | 1 | 500 | 300 | Unipolar | Kontakt | Kaufen |
Technische Dokumentation
| Titel | Typ |
|---|---|
| Electrical Termination and Mounting Configurations of High Voltage Power Supplies Application Notes (307 KB) | Anwendungshinweis |
| Performing Isolation Tests on High Voltage Power Supplies Application Note (426 KB) | Anwendungshinweis |
| HVPS Overview Brochure (735 KB) | Broschüre |
| UltraVolt MPM 100 to 500 Series Data Sheet (538 KB) | Datenblatt |
| UltraVolt MPM 1k-3k Data Sheet (518 KB) | Datenblatt |
Vergleichen Sie
| Model |
MPM Series
|
M Series
|
V Series
|
D Series
|
|---|---|---|---|---|
| Länge (Zoll) | 1.5 | 1.85 | 1.81 | |
| Breite (Zoll) | 1.5 | 1.1 | 0.47 | |
| Höhe (Zoll) | 0.79 | 0.47 | 0.98 | |
| Ausgangsspannungsbereich (V) | 500 to 3000 | 0 to 3000 | 0 to 3000 | 0 to 6000 |
| Maximale Ausgangsleistung (W) | 1.5 | 1 | 1 | 6 |
