OL1K Series
Active
AC-to-HVDC 1 kW Power Supplies Designed for Demanding Requirements
Advanced Energy’s OL1K Series features power switching IGBTs to ensure efficient, reliable operation over the full operating range — even in challenging electrical environments. The OL1K series is fitted with an analog remote-control interface as standard, but units are also available with digital control interfaces.
Eigenschaften
- High power density — 60 kV, 1 kW in 2U format
- Unique Arc Count and Extinguish (ACE) system for managing load arcing
- Efficient and reliable operation
- CE marked for EU LV Directive 73/23/EEC
Vorteile
- Enable significant rack-space savings via compact construction
- Reduce maintenance and safety risks with innovative self-protection arcing system
- Solve for 24 x 7 production processes where high reliability and performance are paramount
- Reduce cost with flexible output options; select only required high voltage capabilities
Spezifikationen
Ausgangsleistung (W): | 1000 |
---|---|
Restwelligkeit (ppm): | <1000 |
Maximaler Ausgangsstrom (A): | 1 |
Ausgangsstrombereich (mA): | 16, 1000 |
Ausgangsspannungsbereich (V): | 1000 to 60000 |
Technische Dokumentation
Vergleichen Sie
Model | OL1K Series | OL400W Series | OL600W Series |
---|---|---|---|
Ausgangsleistung (W) | 1000 | 400 | 600 |
Restwelligkeit (ppm) | <1000 | <1000 | <1000 |
Ausgangsspannungsbereich (V) | 1000 to 60000 | 1000 to 60000 | 1000 to 60000 |
