artesyn™.
PTH03010 Series
Not for New Designs
37.5 W (15 A) Non-Isolated DC-DC Converters
The PTH0310 series of non-isolated DC-DC converters offers some of the industry’s most advanced point-of-load (POL) functions, including Auto-Track™ (a Texas Instruments trademark) sequencing for controlled power-up/power-down of complex semiconductor devices, such as DSPs, FPGAs, and ASICs. These 37.5 W converters offer up to 93% efficiency and are Point-of-Load Alliance (POLA)-compliant. Delivering 15 A and a trimmable output voltage (0.8 to 2.5 VDC) from an input of 2.95 to 3.65 VDC to meet your semiconductor power needs, the converters have an installed height of just 0.35 inch and a small footprint of 0.62 x 1.37 inch. The parts are available in through-hole horizontal and surface-mount versions.
Eigenschaften
- 15 A output current
- 2 Year Warranty
- 3.3 V input voltage
- Efficiencies up to 93%
- Wideoutput voltage adjust (0.8 V to 2.5 V)
- Input voltage range 2.95 - 3.65 V
- Input current 10 mA typ., no load
- Voltage adjustability 0.8 - 2.5 V
- Efficiency 93% max.
Vorteile
- Autotracksequencing*
- Available RoHS compliant
- Margin up/down controls
- Output ON/OFF inhibit
- Output voltage sense
- PointofLoadAlliance (POLA) compatible
- Prebias startup capability
Spezifikationen
| Ausgangsleistung (W): | 37.5 |
|---|---|
| Länge (Zoll): | 1.37 |
| Breite (Zoll): | 0.62 |
| Höhe (Zoll): | 0.354 |
| Montage Typ: | BMP; SMT &Through Hole |
| Minimaler Ausgangsstrom (A): | 0 |
| Maximaler Ausgangsstrom (A): | 15 |
| Ausgangsspannungsbereich (V): | 0.8V to 2.5V |
