Advanced energy’s global footprint helps ease customers’ tariff concerns. This series includes parts that are USMCA qualified.
SL Power™
NGB1200 Series
Active
1200 W Single Output Medical & Industrial Grade
Advanced Energy’s SL Power NGB1200 series AC to DC power supplies features ITE and medical safety approvals. The series offers a choice of three single output models, with voltages of 12 V, 24 V, or 48 V. Each model also provides a 5 V standby output. NGB1200 series power supplies provide 1200 W of output power, and have a typical full load power conversion efficiency of 90%. All models have output overvoltage, short circuit and overload protection and a 3 x 10.8 x 1.6 inch form factor.
Eigenschaften
- Output Power of 1200 W
- 3” W x 10.5” L x 1.6” H Size
- Universal 85 to 264 VAC Input Range
- -20ºC to 70ºC Operating Temperature Range
- Less than 100 uA Leakage Current
Vorteile
- Meets Class B Emissions Levels
- 10+ Years Electrolytic Capacitor Life
- Meets IEC/UL/EN60601-1-1, 3rd Edition
- IEC/UL/EN62368-1 Approved
- Meets 4th Edition/Heavy Industrial EMC
- Class I Input versions available
- 3 Years Warranty
Spezifikationen
| Ausgangsleistung (W): | 1200 |
|---|---|
| Länge (Zoll): | 10.8 |
| Breite (Zoll): | 3 |
| Höhe (Zoll): | 1.6 |
| Montage Typ: | Embedded PSU |
| Minimaler Ausgangsstrom (A): | 25 |
| Maximaler Ausgangsstrom (A): | 100 |
| Ausgangsspannungsbereich (V): | 12V to 48V |
