ARTESYN™
AVD200 Series
Active
200 W 16th Brick DC-DC Converter
Advanced Energy’s Artesyn AVD200-48S12 is a single output DC-DC converter with standard sixteenth-brick outline and pin configuration. It delivers up to 17 A output current with 12 V output voltage. Above 93.9% ultra-high peak efficiency and excellent thermal performance makes it an ideal choice to supply power in telecom and datacom applications.
특징
- Delivering up to 17 A output
- Ultra-high peak efficiency 93.9%
- Wide input range: 36 V ~ 75 V
- ROHS 3.0
- UL94 V-0 materials
- Two year warranty
혜택
- Fully regulated output voltage
- Excellent thermal performance
- No minimum load requirement
- Basic isolation
- Remote control function
- Input under voltage lockout
- Output over current protection
- Output over voltage protection
- Over temperature protection
사양
| 출력 전력(W): | 200 |
|---|---|
| 길이(인치): | 1.3 |
| 너비(인치): | 0.9 |
| 높이(인치): | 0.43 |
| 마운팅 유형: | BMP; SMT &Through Hole |
| 최소 출력 전류(A): | 0 |
| 최대 출력 전류(A): | 17 |
| 출력 전압 범위(V): | 9.6V to 13.2V |
기술 문서
Product Information Documents
Safety & Compliance Certificates
Engineering Resources
기술 동영상
Why EMI Matters in BMP Modules
5월 12, 2026
Electromagnetic Interference (EMI) can compromise system performance, trigger failures, create unexplained system operation, and threaten compliance. Board mounted power modules (BMPs) are common sources of EMI. It's critical to address emissions early. AE's BMP modules provide solutions.
Learn more: https://www.advancedenergy.com/en-us/products/ac-dc-power-supply-units/encapsulated-pcb-mount/acdc-bmp/
