CoolX1800 Series

Active

1800 W Intelligent, Modular Power Supplies

Access incredible power via a compact supply. The modular Excelsys CoolX^®1800 offers 1800 W in a 267 x 127 x 41 mm package (approximately 50% more power than the industry standard). Outputs can be parallel connected for higher currents and series connected for higher voltages (up to 348 VDC). The series is available in two base models. The CX18S has the IEC60950 (second edition) certification for industrial applications and will comply with the upcoming IEC62368-1 standard. The CX18M carries IEC60601-1 (third edition) and the IEC60601-1-2 (fourth edition, EMC) standards for medical applications. Both can be populated with up to six CoolMods, providing up to 12 isolated DC outputs that range from 1.0 V to 615 V.

New CoolX-G option available on CoolX series. This option allows customers and safety agencies to carry out the full 4kVAC and 5.6Kvdc primary to secondary isolation test on complete power supply, exactly as it will be used and installed in their system with no modifications required.

특징

93% efficiency
Five-year warranty
MTBF figures of > 200000
Safety approved to 5000 m altitude

혜택

High Power Density: 1800 W in a 267 x 127 x 41 mm package
Full Safety Agency Approvals: See Technical Specs for details
Intelligent Digital Power: Access maximum flexibility with analog and digital control (PMBus^®)
User- and Field-Configurable: Configure outputs to setpoint voltages; connect in parallel/series for higher output current and/or voltages
High Reliability and Efficiency: Help ensure quality, reliability, and a low total cost of ownership

사양

출력 전력(W):	1800
길이(인치):	10.5
너비(인치):	5
높이(인치):	1.75
출력 전압 범위(V):	1 to 348
최대 출력 전력(W):	1800
최대 입력 전압(V):	264

재고 확인

모델 번호 샘플 구매	효율성(%)	최소. 전압(V)	최대. 전압(V)	전류(A)	공칭 전압(V)	최대 출력 전력(W)	출력 개수	샘플	구매
CMA 활성, 재고 있음 CoolMod 2.5V-6.0V/21A (25A*),must be used with CoolX CoolPac/Flexicharge 요청 구매	93	2.5	6	30	5	150	1	요청	구매
CMB 활성, 재고 있음 CoolMod 6.0V-15.0V/15A (23.3A*) ,must be used with CoolX CoolPac/Flexicharge 요청 구매	93	6	15	23.3	12	280	1	요청	구매
CMC 활성, 재고 있음 CoolMod 15.0V-28.0V/8.33A (12.5A*),must be used with CoolX CoolPac/Flexicharge 요청 구매	93	15	18	12.5	24	300	1	요청	구매
CMD 활성, 재고 있음 CoolMod 28.0V-58.0V/4.17A (6.25A*),must be used with CoolX CoolPac/Flexicharge 요청 구매	93	28	58	6.25	48	300	1	요청	구매
CMDC 활성, 재고 있음 CoolMod Conformal Coated 28.0V-58.0V/4.17A (6.25A*),must be used with CoolX CoolPac/Flexicharge 요청 구매	93	28	58	6.25	48	300	1	요청	구매
CMD-W01 활성, 재고 있음 CoolMod Wide Trim, 3.0V-58.0V/4.17A (6.25A*),must be used with CoolX CoolPac/Flexicharge 요청 구매	93	3	58	6.25	48	300	1	요청	구매
CME 활성, 재고 있음 CoolMod 22.8V-25.2V/25A (37.5A*),must be used with CoolX CoolPac 요청 구매	93	22.8	25.2	37.5	24	900	1	요청	구매
CMF 활성, 재고 있음 CoolMod 45.6V-50.4V/12.5A (18.75A*) ,must be used with CoolX CoolPac 요청 구매	93	45.6	50.4	18.75	48	900	1	요청	구매
CMG 활성, 재고 있음 CoolMod Dual 3.0V-30.0/3A (4A*),must be used with CoolX CoolPac/Flexicharge 요청 구매	93					200	2	요청	구매
CMH 활성, 재고 있음 CoolMod Dual 3.0V-6.0V/6A (10A), 3.0V-30.0V/3A (4A),must be used with CoolX CoolPac/Flexicharge 요청 구매	93					180	2	요청	구매
CMK 활성, 재고 있음 CoolMod 175V-205V/0.6A(1.0A*),must be used with CoolX CoolPac/Flexicharge 요청 구매	93	175	205	1	200	205	1	요청	구매
CX18M-000000-N4A 활성, 재고 있음 1800W Fan Cooled Medical CoolPac, Screw Terminal Input, Low leakage, 12V aux, 6 Slots, must be used with CoolX CoolMod 요청 구매	93	85 VAC Input	264 VAC Input			1800	12	요청	구매
CX18M-000000-N5B 활성, 재고 있음 1800W Fan Cooled Medical CoolPac, IEC input, Low leakage, 5V aux, 6 Slots, must be used with CoolX CoolMod 요청 구매	93	85 VAC Input	264 VAC Input			1800	12	요청	구매
CX18M-000000-N-A 활성, 재고 있음 1800W Fan Cooled Medical CoolPac, Screw Terminal Input, Low leakage, 12V aux, 6 Slots, must be used with CoolX CoolMod 요청 구매	93	85 VAC Input	264 VAC Input			1800	12	요청	구매
CX18M-000000-N-B 활성, 재고 있음 1800W Fan Cooled Medical CoolPac, Screw Terminal Input, Low leakage, 5V aux, 6 Slots, must be used with CoolX CoolMod 요청 구매	93	85 VAC Input	264 VAC Input			1800	12	요청	구매
CX18P1 활성, 재고 있음 CoolX1800 Parallel Links 요청 구매								요청	구매
CX18S-000000-N-A 활성, 재고 있음 1800W Fan Cooled Standard CoolPac, Screw Terminal Input, Low leakage, 12V aux, 6 Slots, must be used with CoolX CoolMod 요청 구매	93	85 VAC Input	264 VAC Input			1800	12	요청	구매
CX18S-000000-N-B 활성, 재고 있음 1800W Fan Cooled Standard CoolPac, Screw Terminal Input, Low leakage, 5V aux, 6 Slots, must be used with CoolX CoolMod 요청 구매	93	85 VAC Input	264 VAC Input			1800	12	요청	구매
CX18S1 활성, 재고 있음 CoolX1800 Series Links 요청 구매								요청	구매

기술 문서

제목	유형
Electrosurgery Application Note (300 KB)	애플리케이션 노트
How to Select Power Supplies for High-Altitude Applications Application Note (2 MB)	애플리케이션 노트
I2C Basics Application Note (576 KB)	애플리케이션 노트
Immunity to ESD Application Note (206 KB)	애플리케이션 노트
Life Science Application Note (305 KB)	애플리케이션 노트
Medical Imaging Application Note (261 KB)	애플리케이션 노트
Medical Lasers and Aesthetic Equipment Application Note (337 KB)	애플리케이션 노트
Semi F47-0706 Compliance: Voltage Sag Immunity Application Note (96 KB)	애플리케이션 노트
Embedded Power (5 MB)	브로셔
Low Voltage Medical Power Supplies Brochure (1 MB)	브로셔
Medical Power Supplies Brochure (11 MB)	브로셔
Rapid Modification & Value-Added Engineering Solutions (2 MB)	브로셔
AE's range of power solutions and responsiveness enables launch market leading Cell Sorter for OEM (1 MB)	사례 연구
CoolX-G Power Supplies for Next Generation Biomedical Analyser (331 KB)	사례 연구
CoolX1800 Data Sheet (3 MB)	데이터 시트
CoolX1800 6X Standard STEP File (23 MB)	그리기
CoolX1800 Designers Manual (2 MB)	매뉴얼
CoolX1800 Instruction Manual (3 MB)	매뉴얼
CX1800 PMBus Manual (632 KB)	매뉴얼

액세서리

CoolXPMBus GUI

The CoolX series PMBus interface facilitates operating parameter communications (e.g. output voltage, output current, and internal temperature) with other PMBus enabled devices.
