MSRZ Series
Active
Reversible, Fast-Switching, and Quadrupole
Obtain reliable performance in challenging conditions. Advanced Energy’s MSRZ series of mass spectrometer power supply modules are ideal for quadrupole mass spectrometer sample ionization and ion detector applications. MSRZ power supplies combine fast-switching, reversible-output voltage, low ripple, and excellent repeatability for precision applications. Customize to meet specific applications requirements and choose from an array of performance features and combinations, which include cable length and connector types.
特点
- Low ripple on bias and detector supplies
- Bias four-quadrant output stage
- Choice of four different models; customer-defined derivatives upon request
益处
- Three standard models and built-to-order variations available
- Use in all major mass spectrometry device types that require high stability and resolution
- Solve for mass spectrometry ion detection performance requirements
- Select needed high voltage capabilities and reduce costs
- Enable efficient and reliable operation
技术文档
比较
| Model | MSRZ Series | MSRF Series | MSP Series |
|---|---|---|---|
| 输出功率（瓦） | 3.2 | 1.25 to 3.2 | 10 |
| 波纹（ppm） | <15 | <50 | <4 |
| 输出电压范围 (V) | ±1000 to ±10000 | ±2500 to ±10000 | 1000 to 20000 |
