ERM150 Railway DC-DC

Active

150 W Quarter Brick

Advanced Energy’s Artesyn ERM150 series is a new generation of high performance, isolated DC-DC converter modules. The product offers 150 W in a small, fully encapsulated package. The input voltage ranges comply with European railway standard EN50155. Reinforced insulation and high EMC immunity qualifies these converters also for many demanding applications in railway and other transportation systems. Advanced circuit topology provides a very high efficiency up to 90% which allows ambient temperatures range up to +85℃ with derating.

特点

Input Voltage 36Vdc to 160Vdc
Isolation 2000V I/O isolation
Approvals EN62368-1, EN50155, IEC60571,
Efficiency 0.915
Form factor Encapsulated 1/4 brick
Mechanical dimensions 1.47 by 2.3 by 0.67
input current 1.55Amps
output voltage 5V, 12V, 15V, 24V, 54V

益处

Enable polarity Positive or Negative enable

规格

输出功率（瓦）:	150
长度（英寸）:	2.3
宽度（英寸）:	1.47
高度（英寸）:	0.67
安装类型:	BMP; Through Hole
最小输出电流 (A):	2.78
最大输出电流 (A):	27
输出电压范围 (V):	4.5V to 59.4V
最小输出功率（瓦）:	0
最大输出功率（瓦）:	150
最大输入电压 (V):	160
保修期（年）:	3

所有规格折叠规格

库存检查

型号	最小值电压 (V)	最大电压电压 (V)	电流 (A)	标称电压 (V)	输出数量	样品	购买
ERM02U100(N)-(HS) 150W 5Vout Railway 1/4 br 联系我们购买	45.9	59.4	2.78	54	1	联系我们	购买
ERM06H100(N)-(HS) 150W 24V Railway 1/4 br 联系我们购买	22.6	26.4	6.25	24	1	联系我们	购买
ERM10C100(N)-(HS) 150W 15V Railway 1/4 br 联系我们购买	13.5	16.5	10	15	1	联系我们	购买
ERM12B100(N)-(HS) 150W 12V Railway 1/4 br 联系我们购买	10.8	13.2	12.5	12	1	联系我们	购买
ERM30A100(N)-(HS) 150W 5Vout Railway 1/4 br 联系我们购买	4.5	5.5	30	5	1	联系我们	购买
