SL Power™
Linear - CBB Series
Active
Low Noise Linear Technology Power Supply
Advanced Energy’s SL Power linear series power supplies are triple output models. The models feature commercial or medical safety approvals and accept a universal input of 100 to 240 VAC. These linear power supplies feature very little output ripple with 3 mV, and low regulation with 0.05% of the output voltages. The power supplies have optional overvoltage protection and short-circuit protection on all models.
特点
- MTBF 200,000+ hours per Mil Handbk 217D (most units)
- All electrolytic caps rated at 105ºC
益处
- World-wide ac input ranges and safety standards
- Industry standard packages
- Burn-in with cycling; 3-year warranty
- Capacitors have highest CV & ripple current ratings
- Transformer insulation meets Class F (155ºC)
- Exceed FCC and CISPR22, Class B conducted emissions
- Approved to IEC62368-1
规格
| 输出功率（瓦）: | 75 |
|---|---|
| 长度（英寸）: | 11 |
| 宽度（英寸）: | 4.88 |
| 高度（英寸）: | 2.75 |
| 安装类型: | Embedded PSU |
| 最小输出电流 (A): | 1 |
| 最大输出电流 (A): | 3.4 |
| 输出电压范围 (V): | 5V to 15V |
