artesyn™
NP08
Active
Up to 4000 W Configurable AC-DC Power Supplies
The NeoPower NP08 AC-DC configurable power supply introduces best-in-class power density of 18 W/in3. For up to 4000 W output power in a 283.4 x 203.2 x 63.5 mm package, NP08 is easy to configure (series or parallel) and has eight output power slots. The NP08 case can be populated with up to 8 output modules, providing up to 8 isolated DC outputs that range from 1.0 to 57.6 V. The NP05 can drop into an OEM’s enclosure to make a custom power supply or simply be used for its high flexibility for any embedded or power conversion challenge requiring multiple outputs.
The NeoPower is certified for both industrial IEC/EN/UL 62368-1 and medical IEC/EN 60601-1 safety approvals, including compliance to the SEMI F47 standard.
The NeoPower is certified for both industrial IEC/EN/UL 62368-1 and medical IEC/EN 60601-1 safety approvals, including compliance to the SEMI F47 standard.
Features
- Market-leading low ripple noise
- Programmable in constant voltage or constant current mode
- MTBF > 500,000 hours
- Five-year warranty
Benefits
- More power in 2.5" configurable compared to the competition
- Flexible communications
- Fast deployment
- Higher power signal and accuracy
- Simplified busbars for any series/parallel combination
- Confidence in reliability from the #1 configurable power supply manufacturer
Specifications
| Length (Inches): | 11.2 |
|---|---|
| Width (Inches): | 8 |
| Height (Inches): | 2.5 |
| Output Voltage Range (V): | 1 to 300 |
| Maximum Output Power (W): | 4000 |
| Minimum Input Voltage (V): | 90 |
| Maximum Input Voltage (V): | 264 |
Accessories Stock Check
Technical Documentation
Product Information Documents
New
Insights & Studies
Miscellaneous
Software
Technical Videos
Advanced Energy Artesyn Configurable NeoPower Unboxing Video
Jan 9, 2025
Advanced Energy’s Artesyn NeoPower (NP) configurable AC-DC power supplies provide high power density as either a programmable voltage or current source. Enabling fast prototypes, NeoPower configurable features an intuitive software interface and user configurable modules. To enable 1,000's of output combinations, modules can be connected in series and parallel with the configurable buss bar system. Advanced Energy's NeoPower is certified for both industrial and medical safety approvals, including compliance to the SEMI F47 standard. The NeoPower supports digital communication with MODBUS RTU for control, monitoring and configuration.
